Skeleton semi trailer with super single tire for light dead weight demand
40 feet Skeleton Semi Trailer with 2 axles and super single Tires for light and Valuable Cargo Container
Skeleton Semi-trailer is a most common type of trailers for container transportation (or Container Chassis) which have light weight but heavy capacity, without floor can easy the tank container's discharge. If choose the Gooseneck type, can lower the clearance to get a better delivery quality for the dangerious tank contianer and Vibration sensitive cargos.
|40 feet Skeleton Semi Trailer with 2 axles and super single Tires for light and Valuable Cargo Container||9332TJZDT|
overall outside dimension（mm）
|Outside dimension of Drop Side body（mm）||Length|
|Skeletal Semi-Trailer GVW（kg）||40000|
|Skeletal Semi-Trailer vehicle total weight（kg）||6300|
|Skeletal Semi-Trailer rated payload（kg）||33700|
|Skeletal Semi-Trailer Wheel base（mm）||7900+1310|
|Trailer Tread（mm）||Tread at front|
|Tread at rear||2040/2040/2040|
|Rated payload of Vehicle saddle||16000|
|Trailer Axle||BPW 12T*2|
|Trailers Axle Capacity kgs||/8000/8000/8000|
|Trailer Material||Carbon Steel|
|Transport Material :||20'*1+2*20'+1*40"|
|ISO Container Twist Locks||4,8,12|
|Tanker Insulated Cover||nile|
|Suspension System||Leaf Spring|
|Leaf Spring Plate||7/7|
|40 ft goose neck type (three single births), Photo: 12 of the lock, the election with a small platform, the guide block and the middle to strengthen the beams and locks, traction pin at frame total height of 210mm. |
Wanan + Comet + under the WABCO cross section size of groove 60 x 160mm high from the 500mm
Material:High strength low alloy steel with 350 MPa yield strength is used for welded I-beam and 235 MPa in other fabricated parts.
Main Beams: 500m deep x 146mm wide x 8mm web welded I-section main beams,Top Flange 14m thick, Bottom Flange 16m thick.
|OEM Parts Configuration:|
King Pin: 3.5” /2” exchangeable king pin, Supplier: JOST.
Container locks: 12 Sets or 8 sets.
Landing Gear: 2 speed road side winding with sand shoe,Type: JOST C200T.
Suspension:Mechanical suspension with 11 / 10/ 8/7 leaf spring (W100mm x T12mm per leaf). options: Bogie Suspension, Air Spring Suspension
Axles: square axle with 12 tons capacity. Supplier & type: BPW/ FUWA/SAF/L1. Made in China..
Rims: 10 Holes ISO. Made in China. Option By the Factory..
Tires: 11R22.5 OPTIONS: 12R22.5, 315/80R22.5,385/65R22.5 , Triangle Brand , Made in China. Option By the Factory..
Brake System: Dual air brake system, Wabco relay emergency valve, OPTIONS: ABS. Option By the Factory.
Brake Chamber: 30 type on front axle.30/30 type on other axles,
Electrical System: Complete 24V installation with modular wiring harness. 7 pole plug placed at front in accordance to ISO, norms NO.1185.
Side Lights: reflectors (orange);
Rear Lights: direction indicators (orange) /brakes (red)/rear warning (white).
Spare Tire Carrier: Equipped two sets per chassis without spare tire.
Side Guard: Steel.
Tool Box: Equipped one set.
Painting: Color by customer’s requirement.
Marking: By customer’s requirement.
Options: Oil Tanker: 300L carbon steel.
