Manhole Cover-C801C-460

Share to:

whole diameter of Manhole Cover 16"
Norminal Diameter of Manhole Cover 10"
Emergency open pressure of Manhole Cover 21KPa-32KPa
Manhole Cover Max emergency flow rate 7000m³/h (When 34 Kpa)
Manhole Cover Material Aluminum Alloy
Manhole Cover Installment mode Flanged Type
Temperature range of Manhole Cover -20~+70℃

  • C801C-460
  • GET,CIMC
Quantity:

Product Parameters

 Manhole   Cover-C801C-460
TANKER PARTS TECHNICAL DATA
whole diameter of   Manhole Cover16"
Norminal Diameter of   Manhole Cover10"
Emergency open   pressure of Manhole Cover21KPa-32KPa
Manhole Cover Max   emergency flow rate7000m³/h (When 34 Kpa)
Manhole Cover   MaterialAluminum Alloy
Manhole Cover   Installment modeFlanged Type
Temperature range of   Manhole Cover-20~+70℃










Description of Manhole Cover
Manhole Cover is installed on the top of the   tanker to prevent the inside fuel from leakage when the tanker is over   rolled. With P/V vent inside to adjust the pressure, When where is pressure   differences inside and outside the tanker, it will automatically inlet or   exhaust air to adjust the pressure so that it can ensure the safety and   environmental protection. It is suitable to transport petroleum, diesel,   kerosene, and the other light fuel, etc
Benefit and Features of Manhole Cover
1. Emergency Exhausting Design
  When the tanker truck is in high temperature condition, the manhole will   automatically exhaust the air inside to release the pressure, ensuring the   safety of the tanker

  2. With P/V vent inside
  When there   is pressure differences inside and outside the tanker it will automatically   inlet or exhaust air to adjust the pressure so that it can ensure the safety   and environmental protection.

  3. Secondary Open Design
  When open the   up blinder plate, it will release the pressure out to prevent the workers’   from pushing over

  4. Blinding holes design
  In the main plate of the manhole, there are three blinding holes can be   installed with vapor vent valve, optic Sensor, Dip tube or Ou Tamale Vacuum   Valve according to the user’s demand

  5. Superior Process Performance
  The main Plate is stamped, it is more light and sturdy
