Product Description
A container chassis, also called intermodal chassis or skeletal trailer, is a type of semi-trailer designed to transport shipping containers. It is a wheeled metal frame onto which a container can be mounted for hauling over roads by a semi-tractor. Container chassis are important to intermodal freight transport.
This chassis is designed for transporting a 40’ 45' 53' ISO container and two 20' ISO contianer with Corner Guider and Locks to fit for the Termianl Crane Vertial Loading and Quick demand, it meets all D.O.T., A.A.R., ANSI, T.O.F.C., FMVSS, SAE and TTMA specifications.
Container Transit semi trailer is mainly used for transporting 20ft and 40ft ISO containers between the factory & Termianl ports.
1. Best structure with lower and Larger Avaliable Loading Platform,
2. Strong & High C apacity,
3. Light Dead weight thanks to the best structure.
4. Beautiful appearance With Europe & America Design
5. Easy and convenient and maintenance on working
6. Cheap Maintain Cost
Front Elevation
Under Beam Elevation
Tail Elevation
40ft 45ft 53ft Skeleton Heavy Duty Container Chassis For container Transit in Terminal | |||
1. Model Of The Truck Trailers (Oem No.) | GET.9TJZ.45MT.2 | ||
This chassis is designed for transporting a 40’ 45' 53' ISO container and two 20' ISO contianer with Corner Guider and Locks to fit for the Termianl Crane Vertial Loading and Quick demand, it meets all D.O.T., A.A.R., ANSI, T.O.F.C., FMVSS, SAE and TTMA specifications. Limited Speed : 25km/h in the terminal. | |||
2. General Parameter Of The Container Truck Trailer | |||
Overall Length | 46 ft | 14,136 mm | |
Overall Width | 9 ft | 2,740 mm | |
Overall Height | 5 ft | 1,550 mm | |
Fifth Wheel Height | 4 ft | 1,200 mm | |
Kingpin Location | 4 ft | 1,100 mm | From the rear face of the front bolster |
Landing Gear Location | 8 ft | 2,420 mm | From the kingpin center |
Axle Spread | 4 ft | 1,310 mm | |
Tandem Location | 30 ft | 9,100 mm | From Kingpin to Front Suspension Hanger |
Tare Weight | 16,540 Ibm | 7,500. kg | |
Payload | 99,210 Ibm | 45,000. kg | |
3. Container Chassi Steel Structure And Trailer Components | |||
Trailer Main beam | Deep: 450 mm (17.7") Auto-welt Main Beam With High strength low alloy steel with 350 MPa yield hot-rolled I-beam (Q345) | ||
Kingpin Upper coupler | 1/4” pick up plate with JOST 2” diameter square type king pin per SAE standard | ||
Flatbed Front Bolster | ASTM A572 grade 50 steel U form channel with 7'' wide x 6'' high x 5/16 thick open section, 3/8'' top plate | ||
Rear Bolster | ASTM A572 grade 50 steel U form channel with 7'' wide x 7'' high x 5/16 thick open section, 3/8'' top plate | ||
Rear Bumper | 100x100mm (4” x 4” ) square tube step with taper “H” section vertical member | ||
Bar is welded to uprights and main beam. | |||
Corner Guider and Locks | 4 Couples of corner Locks at the side and 2 couples of Corner Guider at the head and tail To Guide the Contianer Locate to the container Chassis from Vertical position and Secure the container Horizontal and longitudinal Movements are restricted during moving.It is for Terminal Container Chassis Only | ||
4. Container Trailer Chassis Running Gears and Safty Valves | |||
Landing gear | Jost Or CIMC Brand 28T two speed telescopic manual landing gear | ||
Crank handle is located on the driver’s side of the chassis. | |||
Trailer Suspension | Mechanical tandem suspension with 3-leaf springs. Options: Air Spring Suspension , Bogie Suspension | ||
Axles | 150mm (6") Square axles with 13T/15T/16T/20T capacity, 10 HUB piloted hubs with outboard mounting cast steel drum (ABS Options) Option : Disc Type Manufacturer: FUWA ,Options: BPW,SAF | ||
Wheels | steel disc wheel, 10 holes ISO, ; Option: Aluminum alloy rim | ||
Tires | Tubeless Tires , 12.00R20 (dual Tire), Options : Solid Tire 10.00-20 | ||
Brake System | Dual line pneumatic brake, SAE hose and connector, WABCO relay emergency valve, OPTIONS: ABS brake system | ||
T30/30 spring brake chambers, T30 brake chambers | |||
3/8” blue air tube for control and 3/8” red for supply, 40L air tanks | |||
Electrical | OPTRONICS 12-volt LED lighting with Phillips mold seal wiring harness, meet DOT and SAE standards. Receptacle::7 way socket SAE standard, China Wiring: Electric cable protected by PVC conduit on main frame | ||
Painting | Electrophoretic spraying, that is, water-based coating, can be dissociated into a water-soluble film-forming material which can form a film in water, and swims to the opposite electrode in a direct current electric field, and precipitates on the surface of the object to form a coating film | ||
MISC | GET standard marking, document holder, conspicuity tape, Steel or black rubber mud flaps | ||
Option | Hubodometer, PSI tire inflation system |
Customized Capacity Design
Wabco Brake
Best Axles & Suspension
Producing lines & Shipment
Trailer Details
Angola 500 Units
Tanzania- 100 units @SKD
Nigeria-600 units Flat Packed
