30cbm Rounded Tipper Semi Trailer with 3 Axles And Hydraulic Dumper for Mine And Construction Material

Share to:
sharethis sharing button
U Dump Semi Trailer
Volume: 30 cbm
Axle No. 3 Sets
Hydraulic System: Front tipper System
  • GET.9303ZZXU

  • GET VEHICLES | TrailerBull

  • 8716


Product Parameters

30CBM U type hydraulic Tipper Dump Semi Trailer with 3 Axles and hydraulic  dumper for mine and construction materialDump Semi Trailer,Tipper

Dump Semi-trailers ("British" Tippers) are trailers in which one end can be raised to allow the cargo (often building materials or Agricultural produce) to slide out the other end. Commonly, they are hinged at the rear and raised at the front, but side-unloading dump trailers also are used.

The key advantage of a semi end dump is a large payload. A key disadvantage is that they are very unstable when raised in the dumping position limiting their use in many applications where the dumping location is uneven or off level.

30CBM Rounded Dump Semi Trailer with 3 Axles and hydraulic  dumper for mine and construction materialGET.9303ZZXU
Truck Trailer
    overall outside dimension(mm)
Height (unload)3360
Outside dimension of Drop Side   body(mm)SizeLength9440
Height 1500
thicknessFloor 8mm
Side wall6mm
capacityL30   CBM
vehicle   Tare weightkg9000
rated   payloadkg45000
Wheel   basemm5617+1310+1310
TreadmmTread   at front
Tread at rear1830/1830/1830
Front/Rear   Overhangmm/950
Trailer   Material Carbon   Steel
Transport   Material : Soil,   Coal,Grain,Stones,Sands
Twist Locks
Insulated   Covernile
SuspensionLeaf   Spring
Leaf Spring
Hydraulic system:front   dump rear discharge
Steel Structure:
Material:High   strength low alloy steel with 350 MPa yield strength is used for welded   I-beam and 235 MPa in other fabricated parts.
OEM Parts Configuration:
King Pin: 3.5”   exchangeable king pin, Supplier:   JOST.
Landing Gear: 2 speed   road side winding with sand shoe,Type: JOST A200T.
Suspension:Mechanical suspension with 11 / 10/   8/7 leaf spring (W100mm x T12mm per leaf). options: Bogie Suspension, Air   Spring Suspension
Axles: square axle   with 15 tons capacity. Supplier & type: BPW/ FUWA/SAF/L1. Made in   China..
Tires with rims:   11R22.5 OPTIONS: 12R22.5, 315/80R22.5,385/65R22.5 Made in China. Option:   Michelin,Firestone,goldyear,double coin
Brake System: Dual   air brake system, Wabco relay emergency valve, OPTIONS: ABS.
Brake Chamber: 30   type on front axle.30/30 type on other axles,
Electrical System: Complete   24V installation with modular wiring harness. 7 pole plug placed at front in   accordance to ISO, norms NO.1185.
    Spare Tire  Carrier: Equipped two   sets per chassis without spare tire.
    Side Guard: Steel.
    Tool Box: Equipped one set.
    Painting: Color by customer’s requirement.
    Marking: By customer’s requirement.
    Options: Oil Tanker: 300L carbon steel.
                    Tarpaulin Cover   System
