55000L LNG Tanker Semi Trailer with 3 Axles for Liquid Natural Gas,LNG Tanker Semi Trailer

Share to:
sharethis sharing button
LNG Tanker Semi trailer
Volume: 55000L
Inner/ Exterior Tanker Material: SUS304/Q345R
Thermal Insulation : High-Vacuum Multi-Layer Insulation
  • 9553GDY

  • GET

  • 8716

Availability:
Quantity:

Product Parameters

55000L LNG Tanker Semi Trailer with  3 Axles for Liquid  Natural Gas,LNG Tanker Semi Trailer


LNG Tank trailer or tanker Trailer (United States usage) or tanker (United Kingdom usage), is a Trailer designed to carry Liquefied natural gas (LNG) is natural gas (predominantly methane, CH4, with some mixture of ethane C2H6) that has been converted to liquid form for ease and safety of non-pressurized storage or transport.The natural gas is then condensed into a liquid at close to atmospheric pressure by cooling it to approximately −162 °C (−260 °F); maximum transport pressure is set at around 25 kPa (4 psi). Because of LNG achieves a higher reduction in volume than compressed natural gas (CNG) so that the (volumetric) energy density of LNG is 2.4 times greater than that of CNG (at 250 bar) or 60 percent that of diesel fuel. This makes LNG cost efficient in marine transport over long distances and populared as an clean energy in these years.


55000L LNG Tanker semi trailer with  3 axles for Liquid  Natural Gas 9553GDY
overall dimension of the vehiclemmLength13000
Width2500
Height (unload)3890
Overall dimension of outer shellmmLength12850
Dia Φ2488
Overall dimension ofInner vesselmmLength12750
Dia Φ2488
capacityL555000
GVWkg40000
vehicle total weightkg18500
rated payloadkg21500
Wheel basemm6960+1320+1320
TreadmmTread   at front
Tread at rear1840/1840/1840
Front/Rear Overhangmm/1520
Approach/Departure angle°/17
Rated payload of Vehicle saddle16000
AxleBPW   12T*3
Axle Capacity kgs8000/8000/8000
Tyres12R22.5*12
Tank Material S30408+Q345R
Transport Material : LNG
Insulated Cover
SuspensionSpring   Leaf
Leaf Spring/8/8/8
remark:
Storage Tank volume:55.5 m3,LNG : 387.4kg/m3,   WABCO Brake System and ABS, Clerance: 540
    OPTIONAL : Spring Air SUSPENSION AND SUPER SINGLE TYRE
Tank facility
Design pressure0.7MPa
     (see technical proposals)
MAWP0.92MPa
    (see technical proposals)
Capacity
Code   & MaterialStainless Steel 304/ Q345R
vacuum   Degress of Interspace Pa≤1*10^-1 Absolute Pressure
Static Evaporation %/D≤0.21 (LN2)
Thermal Insulation typeHigh-Vacuum Multi-Layer Insulation
Filling & Discharge System Control   method Mechanical
Liquid discharge Single   liquid discharge system Side   of the trailer
Valve boxSingle   valve boxes Side   of the trailer
ValesBrand

Emergency Valve (Liquid Phase)Rego

Emergency Valve(Gas Phase)Rego

PRV Rego

Vent ValveRego

Liquid AdaptorRego

Gas AdaptorRego

Liquid Adapter CapRego

Gas Adapter CapRego

Pressure GaugeRego

Angle ValveFisher

ThermometerWIKA

Liquid Level GaugeRego

Ball valves (Liquid Phase)Modentic   valve

Ball valves (Gas Phase)Modentic   valve

Main Instruction


Liquefied natural gas (LNG) is natural gas   (predominantly methane, CH4, with some mixture of ethane C2H6) that has been   converted to liquid form for ease and safety of non-pressurized storage or   transport.The natural gas is then condensed into a liquid at close to   atmospheric pressure by cooling it to approximately −162 °C (−260 °F);   maximum transport pressure is set at around 25 kPa (4 psi). Because of LNG   achieves a higher reduction in volume than compressed natural gas (CNG) so   that the (volumetric) energy density of LNG is 2.4 times greater than that of   CNG (at 250 bar) or 60 percent that of diesel fuel. This makes LNG cost   efficient in marine transport over long distances and populared as an clean   energy in these years.

    G.E.T Vehicles provides light weight and high-volume Liquefied GAS   Transportation (LNG) tank semi-trailer with 3 axles and more to customers.   With 56000-liter max volume, 1.0 Mpa, Super vacuum multi-layer insulation are   used for Support of inner tank and outer tank parts; European ADR standard   and ASME STANDARD, it is an optimal transporter for ENERGY logistic industry.

    Series of products: LNG cryogenic liquid Trailer, Cryogenic Industrial Gas   Trailer, etc.
    Thermal-insulating mode
Super vacuum multi-layer insulation
OEM Parts Configuration:

    King Pin: 3.5” /2”  JOST.
    Landing Gear: 2 speed road side winding with sand shoe,Type: JOST   C200T.
    Suspension:Mechanical  with 11 / 10/   8/7 leaf spring (W100mm x T12mm per leaf). options: Bogie Suspension, Air   Spring Suspension
    Axles: square axle with 12 tons capacity. Supplier & type: BPW/   FUWA/SAF/L1.
    Tires: 11R22.5 OPTIONS: 12R22.5, 315/80R22.5,385/65R22.5 , Triangle Brand ,   Made in China.
    Brake System: Dual air brake system, Wabco relay emergency valve, OPTIONS:   ABS.
    Electrical System: Complete 24V installation with modular wiring harness. 7   pole plug placed at front in accordance to ISO, norms NO.1185.
    Side Lights: reflectors (orange);
    Rear Lights: direction indicators (orange) /brakes (red)/rear warning   (white).
Others:

Spare Tire    Carrier: Equipped two sets per chassis   without spare tire.

Side Guard:   Steel.

Tool Box: Equipped   one set.

Painting: Color by   customer’s requirement.

Marking: By   customer’s requirement.

Options: Oil   Tanker: 300L carbon steel.


Main Instruction

We not only in the normal Carbon Steel and Aluminum tank , but also specializes in design, manufacturing, sales and technical service of various cryogenic equipments, including Cryogenic Liquid Storage Tank, Cryogenic Liquid Lorry Tanker, Large Pressure Tank, Liquid Tank Container, Cryogenic Thermal-insulating Cylinder, Vaporizer, Hazardous chemical storing and transporting equipments. We also gets involved in establishment of LNG applied projects and industrial gas applied projects.


Thermal-insulating mode:Super vacuum multi-layer insulation

Capacity:5M3-36M3

Working Pressure:0.3MPa-1.6MPa

Medium:LOX、LIN、LAr、LCO2、LC2 H 4、LH2  etc

Features:For material, we raise products efficiency with use of new material-the high strength stainless steel. We realize the maximum capacity among similar products, lower self-weight of vehicle as well as lower operation cost.
