80ft draw bar double FlatBed Semi Trailer Train with 1 flatbed trailer and 1 draw bar trailer
Flatbed Semi-trailer is a most common type of Drop-deck trailers (or Step-frame Trailer) which have a floor that drops down a level once clear of the tractor unit; It have no front axles and coupling with towing vehicle by fifth wheel, this can make semi-trailers have a long continuous cargo area for longer objects (logs, pipe, beams, railway track, containers) than full trailers.
|80ft draw bar Double FlatBed Semi Trailer Train with 1 flatbed trailer and 1 draw bar trailer||96-606TJZP|
|This Trailer Trailer include 1 unit of 40 ft Flatbed semi-trailer and 1 units 40ft draw bar trailer, it is for the desert straight road transportation like Australia.|
|Container Flat Bed Semi-Trailer |
Overall Outside Dimension（mm）
|Flat Bed Semi-Trailer GVW（kg）||60,000|
|Flat Bed Semi-Trailer Vehicle Tare Weight（Kg）||7,500+9,000|
|Flat Bed Semi-Trailer Rated Payload（Kg）||30,000+30,000|
|Flat Bed Semi-Trailer Wheel base（mm）||8200+1310/8200+1310|
|Tread（mm）||Tread at front|
|Tread at rear||1830|
|Rated payload of Vehicle saddle||17070|
|Leaf Spring suspension||BPW 13T*6|
|Contaner twist locks||8 or 12|
Material:High strength low alloy steel with 350 MPa yield strength is used for welded I-beam and 235 MPa in other fabricated parts.
Main Beams: 500m deep x 146mm wide x 8mm web welded I-section main beams,Top Flange 14m thick, Bottom Flange 16m thick.
Floor：3mm thick checkered steel plate.
|OEM Parts Configuration:|
King Pin: 3.5” /2” exchangeable king pin, Supplier: JOST.
Container locks: 12 Sets or 8 sets.
Landing Gear: 2 speed road side winding with sand shoe,Type: JOST C200T.
Suspension:Mechanical suspension with 11 / 10/ 8/7 leaf spring (W100mm x T12mm per leaf). options: Bogie Suspension, Air Spring Suspension
Axles: square axle with 12 tons capacity. Supplier & type: BPW/ FUWA/SAF/L1. Made in China..
Rims: 10 Holes ISO. Made in China. Option By the Factory..
Tires: 11R22.5 OPTIONS: 12R22.5, 315/80R22.5,385/65R22.5 , Triangle Brand , Made in China. Option By the Factory..
Brake System: Dual air brake system, Wabco relay emergency valve, OPTIONS: ABS. Option By the Factory.
Brake Chamber: 30 type on front axle.30/30 type on other axles,
Electrical System: Complete 24V installation with modular wiring harness. 7 pole plug placed at front in accordance to ISO, norms NO.1185.
Side Lights: reflectors (orange);
Rear Lights: direction indicators (orange) /brakes (red)/rear warning (white).
Spare Tire Carrier: Equipped two sets per chassis without spare tire.
Side Guard: Steel.
Tool Box: Equipped one set.
Painting: Color by customer’s requirement.
Marking: By customer’s requirement.
Options: Oil Tanker: 300L carbon steel.
